A 6-pole three-phase induction motor is connected to a 1000v 50 Hz
supply. At full load, its speed is 960 rev/min. It has a stator
resistance of 0.4 Ω per phase and a rotor resistance of
4.0 Ω per phase with a rotor/stator turns ratio of 0.8/1
Calculate the:
a) full load torque
b) maximum torque
Dear All,
In this problem, the rotor reactance is not provided. If the rotor reactance were given, the problem could be solved. Please advise on alternative methods to solve this issue.
